Palm oil, as one of the most widely consumed vegetable oils globally, is extensively used in food processing, daily chemical manufacturing, and bioenergy. For palm oil mills, stable production increases are directly related to the company's market competitiveness and economic benefits. However, due to various factors such as raw material quality, processing technology, and equipment performance, many palm oil mills face problems such as low capacity utilization and resource waste. So, how to scientifically and efficiently increase palm oil yield? Based on Henan Huatai Cereals and Oils Machinery Co., Ltd.'s 37 years of experience in R&D and manufacturing of grain and oil processing equipment and project practices in more than 60 countries and regions worldwide, this article will provide practical solutions from key aspects.
1. Controlling Raw Material Sources: Laying the Foundation for High Yield
Raw material quality is the prerequisite for determining palm oil yield. High-quality and properly processed palm fruit bunches can improve palm oil extraction rates from the source. Practice shows that the maturity, freshness, and pretreatment effect of palm fruit directly affect the subsequent processing capacity conversion.
In the raw material receiving and pretreatment stages, Henan Oil Huatai provides a systematic solution.
1) A raw material receiving platform with fully hydraulic segmented unloading is used to achieve efficient unloading, cleaning, and temporary storage of palm fruit, avoiding equipment wear and oil contamination caused by impurities.
2) Considering the characteristic of palm fruit being prone to fermentation and spoilage, Henan Huatai's vertical/horizontal sterilization tanks can accurately control the temperature (130-145℃) and time (90-120 minutes). Through steam sterilization, the enzyme activity is destroyed, preventing fruit pulp spoilage, and simultaneously softening the fruit bunches to improve the subsequent fruit separation rate.
3) Its patented palm oil threshing machine achieves efficient separation of fruitlets from fruit bunches through strong vibration, reducing raw material waste and laying the foundation for the subsequent palm oil extraction process.
It is worth noting that palm fruit needs to be processed within 24 hours after harvesting; otherwise, fermentation and hydrolysis may occur, leading to increased free fatty acids and decreased oil yield. Henan Huatai's palm oil production line adopts a modular design, which can be flexibly configured according to the palm oil mill's capacity (10-1000 TPD), ensuring efficient connection of the entire process from receiving and sterilization to fruit separation, maximizing the retention of oil content in the raw materials.
2. Optimizing Core Processes: Enhancing Oil Extraction Efficiency
The palm oil extraction process is central to increasing yield. Precise control of process parameters and the performance advantages of the equipment directly determine the oil yield. Traditional palm oil extraction equipment generally suffers from high residual oil rates, high energy consumption, and extensive manual intervention, which limits capacity improvement.
Targeting the specific characteristics of palm oil processing, Henan Huatai has independently developed a patented double-screw oil press. By optimizing the screw structure and pressing parameters, it achieves thorough crushing of the fruit pulp, allowing the oil to be extracted more easily. Compared to traditional equipment, the palm oil yield is increased by 5% to 10%, and the residual oil rate is significantly reduced.
For crude palm oil processing, Henan Huatai's vibrating screen + clarification tank combination system efficiently removes solid impurities from the crude oil through processes such as hot water viscosity reduction and high-temperature separation (85-90℃), improving the purity of the crude oil and reducing losses in subsequent refining stages. In addition, Huatai Oil Machinery has also equipped a palm kernel recovery system. Through a fiber separator, it achieves efficient separation of palm kernels and fibers from the press cake. The recovered palm kernels can be further pressed to extract palm kernel oil, maximizing resource utilization and indirectly increasing the overall capacity of the palm oil mill.
3. Upgrading Intelligent Equipment: Achieving High Efficiency and Stable Production
In large-scale palm oil production, the automation level and stability of the palm oil equipment directly affect production capacity stability. Traditional palm oil production lines rely on manual operation, which is prone to fluctuations in process parameters and frequent equipment failures, leading to unstable production capacity. Henan Huatai integrates intelligent technology into its palm oil production line, achieving a dual improvement in capacity and efficiency.
Huatai's palm oil production line uses a PLC central management system, enabling automated control of the entire process from raw material processing and pressing to crude oil treatment. This includes real-time monitoring and precise adjustment of parameters such as temperature, pressure, and conveying speed, reducing manual intervention and ensuring process stability while lowering labor costs. For example, the complete set of 50TPD palm fruit oil pressing equipment customized for a client in Ghana utilizes an intelligent power distribution control system to ensure the safe and efficient operation of all equipment. The accompanying environmentally friendly wastewater treatment module achieves green, compliant discharge, solving the problems of high pollution and low production capacity faced by traditional local palm oil mills.
To meet the needs of palm oil mills of different sizes, Henan Huatai offers three palm oil refining process solutions: continuous, semi-continuous, and batch processes.
1) Large palm oil mills (50-600 TPD) are suited to continuous palm oil refining lines for large-scale, efficient production;
2) Medium-sized palm oil mills (10-50 TPD) can choose a semi-continuous palm oil refining process to balance capacity and cost;
3) Small palm oil mills (1-10 TPD) are best suited to batch refining equipment, providing flexibility to meet production needs.
The complete set of 100 T/D palm oil refining and fractionation equipment built for a client in the Democratic Republic of Congo, with its highly mechanized and automated design, not only ensures that the oil quality meets international standards but also reduces water, electricity, and steam consumption by 15%-30%, significantly improving the company's production efficiency and market competitiveness.
4. Full-Cycle Service Guarantee: Ensuring Stable Production Capacity
The stable operation of palm oil equipment and continuous optimization of processes are key to maintaining high yields in the long term. Henan Huatai provides customers with a full life-cycle turnkey service, from project design and equipment manufacturing to installation, commissioning, and after-sales training, ensuring the rapid commissioning and stable operation of palm oil production lines.
Before project implementation, the Huatai's engineering team thoroughly understands the client's raw material characteristics, production capacity requirements, and local environmental conditions to customize a palm oil production line solution. High-end equipment such as laser cutting machines and fully automatic welding robots are used in the equipment manufacturing process to ensure precision and quality. After project completion, a professional technical team provides full support for installation and commissioning, conducts operator training, and offers long-term after-sales service and technical upgrade support.
Conclusion: Technology Empowers High-Yield Upgrading of the Palm Oil Industry
Increasing palm oil production is not merely about optimizing a single aspect, but rather a systematic engineering process involving raw material control, process optimization, equipment upgrading, and service guarantees. With 38+ years of industry experience, Henan Huatai, leveraging its proprietary patented technology, modular and intelligent equipment, and comprehensive lifecycle services, provides global palm oil mill plants with practical high-yield solutions. Its products have been proven in benchmark projects in several countries, including Cameroon, Nigeria, Ghana, and the Democratic Republic of Congo, helping clients achieve increased capacity and profitability.
